You are looking for an alternative to Tyco, Molex, Iriso, JST and many others? They should have the same standards of quality and shorter delivery times? And at the same time be interesting in terms of prices? Then you have found the perfect partner in CviLux!
The company from Taiwan with several production sites in the Far East offers a wide range of connectors and cables. See for yourself!
CviLux's main product portfolio is:
- FFC / FPC Connector
- FFC Cable
- IDC Cable incl. Ribbon Cable
- Pin Header
- Jack, USB and Power Connector
- Wire-to-Board Connector
- USB-C Connector, -Socket und -Cable
CviLux is certified for ISO9001, ISO14001 and IATF16949 amongst others.
Silke Pfeifer
Sales
Telefon:0911 47496-271
E-E-Mail:silke.pfeiferbeck-elektronik[dot]de
CviLux Connector Overview
Tabs
Wire To Board
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | Remark |  |
|---|---|---|---|---|---|---|---|---|---|
| 0.60 | 0.024 | CI20 | 6, 8, 10 | without | SMT | Male / Female | 1 | Wire to Board Housing & SMT Headers | Download |
| 0.80 | 0.031 | CI18 | 2-15 | without | SMT | Male / Female | 1 | Wire to Board Housing & SMT Headers | Download |
| 1.00 | 0.039 | CI11 | 02-15, 18, 20, 26 | without | SMT | Male / Female | 1 | Single Row Wire to Board Housing & Terminal | Download |
| 1.00 | 0.039 | CI11 | 10, 12, 14, 16, 18, 20, 30, 40, 50 | without | SMT | Male / Female | 2 | Double Row Wire to Board Housing & Terminal | Download |
| 1.00 | 0.039 | CI14 | 2-20, | with | SMT | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 1.00 | 0.039 | CI16 | 2-20 | without | SMT | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 1.20 | 0.048 | CI63 | 2-10 | without | SMT | Male / Female | 1 | Wire to Board Header | Download |
| 1.25 | 0.049 | CI40 | 02-15 | without | SMT | Male / Female | 1 | Wire to Board Housing & Terminal & SMT Header | Download |
| 1.25 | 0.049 | CI42 | 02-20 | with | SMT | Male / Female | 1 | Wire to Board Housing & Terminal | Download |
| 1.25 | 0.049 | CI43 | 02-15, 20, 25, 30 | without | SMT | Male / Female | 1 | Wire to Boars Housing & Terminal & SMT Header | Download |
| 1.25 | 0.049 | CI44 | 2-15 | without | DIP/SMT | Male / Female | 1 | Wire to Boars Connectors Housing & Terminal | Download |
| 1.25 | 0.049 | CI45 | 19 | with | SMT | Male / Female | 1 | Wire to Board Housing & SMT Headers | Download |
| 1.25 | 0.049 | CI46 | 2-20 | with | SMT | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 1.25 | 0.049 | CIDL | 3 | with | Male / Female | 1 | Wire to Board Connectors | Download | |
| 1.25 | 0.049 | CIDM | 2-15 | without | Male | Download | |||
| 1.27 | 0.050 | CI94 | with | Female | Download | ||||
| 1.50 | 0.059 | CI15 | 2-15 | without | DIP/SMT | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 1.50 | 0.059 | CI19 | 02-20 | without | SMT | Male / Female | Wire to Board Connectors Housing & Terminal | Download | |
| 1.50 | 0.059 | CI87 | 8, 10 | without | SMT | 1 | Wire to Board Housing & Terminal & SMT Header | Download | |
| 1.80 | 0.071 | CI07 | 2 | with | SMT | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 2.00 | 0.079 | CI01 | 02-16 | with | DIP/SMT | Male / Female | 1 | Single Row Wire to Board IDC Housing & Terminal | Download |
| 2.00 | 0.079 | CI01 | 02-16 | with | DIP | Male / Female | 2 | Double Row Wire to Board Housing & Terminal | Download |
| 2.00 | 0.079 | CI02 | 02-20 | without | 1 | Board In Connectors | Download | ||
| 2.00 | 0.079 | CI03 | 1 | Download | |||||
| 2.00 | 0.079 | CI04 | 2 | Download | |||||
| 2.00 | 0.079 | CI08 | 03-17 | without | DIP/SMT | Male / Female | 1 | Wire to Board Connectors SMT & DIP Headers | Download |
| 2.00 | 0.079 | CI09 | 2-10 | with | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 2.00 | 0.079 | CI06 | 02-16 | with | DIP/SMT | Male / Female | Wire to Board Connectors Housing & Terminal | Download | |
| 2.50 | 0.098 | CI21 | 02-15 | without | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 2.50 | 0.098 | CI22 | 02-20 | without | DIP | Male / Female | 1 | Wire to Boars IDC Connectors Header | Download |
| 2.50 | 0.098 | CI23 | 02-12 | without | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 2.50 | 0.098 | CI25 | 02-15 | without | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 2.50 | 0.098 | CI26 | 02-16 | without | 1 | Board In Connectors | Download | ||
| 2.50 | 0.098 | CI27 | 02-16 | 1 | Board In Connectors | Download | |||
| 2.50 | 0.098 | CI30 | 2-20 | without | DIP | Male | Download | ||
| 2.50 | 0.098 | CI60 | 02-15 | with | DIP | Male / Female | 1 | Download | |
| 2.50 | 0.098 | CI91 | 3.6 | Female | Straight Wire Holder Connectors | Download | |||
| 2.50 | 0.098 | CIL4 | 2 | without | SMT | Wire to Board Connectors SMT Headers | Download | ||
| 2.54 | 0.100 | CI31 | 2-20 | with | DIP | Male / Female | Wire to Board Connectors Housing & Terminal | Download | |
| 2.54 | 0.100 | CI32 | 1-40 | without | Female | 1 | Wire to Board Connectors Housing & Terminal | Download | |
| 2.54 | 0.100 | CI33 | 2-18 | with | DIP | Male / Female | 1 | Single Row Wire to Board Connectors Housing | Download |
| 2.54 | 0.100 | CI33 | 4-60 | with | Female | 2 | Download | ||
| 2.54 | 0.100 | CI34 | 4-40 | without | Female | 2 | Dual Row Wire to Board Connectors Housing | Download | |
| 2.54 | 0.100 | CI35 | 4 | without | Male / Female | 1 | Wire to Board Connectors | Download | |
| 2.54 | 0.100 | CI83 | 2-36 | with | DIP | Male | 1 | Friction Lock Breakaway Headers | Download |
| 2.54 | 0.100 | CI88 | 2-28 | without | DIP | Male | 1 | Pin Headers | Download |
| 2.54 | 0.100 | CID2 | 2-24 | Female | IDC Type Connectors | Download | |||
| 2.54 | 0.100 | CID7 | 2-22 | with | DIP | Male / Female | 1 | Wire to Board Housing/Terminal/Straight Headers | Download |
| 3.96 | 0.156 | CI51 | 2-20 | without | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 3.96 | 0.156 | CI52 | 2-13 | with | DIP | Male / Female | 1 | Wire to Board Connectors Housing & Terminal | Download |
| 3.96 | 0.156 | CI77 | 2-20 | without | DIP | Male | 1 | Breakaway Pin Headers | Download |
| 3.96 | 0.156 | CI82 | 2-24 | with | DIP | Male | 1 | Friction Lock Breakaway Headers | Download |
| 5.00 | 0.197 | CI78 | 2-20 | 1 | Breakaway Pin Headers | Download | |||
| 5.08 | 0.200 | CI55 | 2-10 | with | DIP | Male / Female | 1 | Wire to Board Connectors | Download |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | Remark | |
Tabs
Board to Board
| Pitch (mm) | Pitch (inch) | Series | Pins | SMD / THT | Male / Female | Rows | |
|---|---|---|---|---|---|---|---|
| 0.50 | 0.020 | CBRB | 010-080 | SMT | 2 | Download | |
| 0.50 | 0.020 | CBRB | SMT | 2 | Download | ||
| 0.50 | 0.020 | CBRC | SMT | 2 | Download | ||
| 0.50 | 0.020 | CBRC | 10-22 | SMT | 2 | Download | |
| 0.50 | 0.020 | CBRE | 10, 20, 30 | SMT | 2 | Download | |
| 0.50 | 0.020 | CBRE | SMT | 2 | Download | ||
| 0.50 | 0.020 | CBRE | SMT | 2 | Download | ||
| 0.80 | 0.032 | CBC3 | 06-39 | SMT | 2 | Download | |
| 0.80 | 0.031 | CBRD | SMT | 2 | Download | ||
| 0.80 | 0.031 | CBRD | 010-080 | SMT | 2 | Download | |
| 1.00 | 0.039 | CB03 | 06-100 | SMT | Female | 1 | Download |
| 1.00 | 0.039 | CB12 | 6-100 | SMT | Female | 2 | Download |
| 1.27 | 0.050 | CB01 | 4-50 | DIP / SMT | Female | 1 | Download |
| 1.27 | 0.050 | CB50 | 06-60 | SMT | Female | 2 | Download |
| 1.27 | 0.050 | CB51 | 6-100 | SMT | Female | 2 | Download |
| 1.27 | 0.050 | CBC1 | 10, 20, 30-60 | SMT | 2 | Download | |
| 1.27 | 0.050 | CBC1 | 06-60 | DIP | 2 | Download | |
| 2.00 | 0.079 | CB22 | 02-40 | DIP / SMT | Female | 1 | Download |
| 2.00 | 0.079 | CB71 | SMT | Female | 2 | Download | |
| 2.00 | 0.079 | CB74 | 04-80 | DIP / SMT | Female | 2 | Download |
| 2.00 | 0.079 | CB76 | 04-80 | SMT | Female | 2 | Download |
| 2.00 | 0.079 | CB78 | DIP | Female | 2 | Download | |
| 2.50 | 0.098 | CBWG | DIP | 2 | Download | ||
| 2.54 | 0.100 | CB33 | 02-40 | DIP | Female | 1 | Download |
| 2.54 | 0.100 | CB37 | 02-40 | DIP | Female | 1 | Download |
| 2.54 | 0.100 | CB39 | 02-40 | DIP | Female | 1 | Download |
| 2.54 | 0.100 | CB41 | 40-80 | SMT | Female | 2 | Download |
| 2.54 | 0.100 | CB72 | SMT | Female | 2 | Download | |
| 2.54 | 0.100 | CB82 | DIP | Female | 2 | Download | |
| 2.54 | 0.100 | CB83 | 04-80 | DIP | Female | 2 | Download |
| 2.54 | 0.100 | CB85 | 04-80 | DIP | Female | 2 | Download |
| 2.54 | 0.100 | CB87 | DIP | Female | 2 | Download | |
| 2.54 | 0.100 | CB91 | 04-50, 60, 64, 66, 80 | DIP | Female | 2 | Download |
| 2.54 | 0.100 | CB93 | DIP | Female | 1 | Download | |
| 2.54 | 0.100 | CB94 | 06-64 | DIP | Female | 2 | Download |
| 2.54 | 0.100 | CB96 | 06-80 | DIP | Female | 2 | Download |
| 2.54 | 0.100 | CB97 | 04-40 | DIP | Female | 2 | Download |
| Pitch (mm) | Pitch (inch) | Series | Pins | SMD / THT | Male / Female | Rows | |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Remark | |
|---|---|---|---|---|---|---|---|
| 0.30 | 0.012 | CF30 | 11-45 | SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 0.30 | 0.012 | CF38 | 13-71 | SMT | ZIF One-Touch FFC/FPC Connector | Download | |
| 0.30 | 0.012 | CF58 | 07-61 | SMT | ZIF FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF11 | 04-60 | SMT | Download | ||
| 0.50 | 0.020 | CF20 | 04-55 | SMT | ZIF FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF23 | 04-40 | SMT | ZIF FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF24 | 04-50 | Download | |||
| 0.50 | 0.020 | CF25 | 05-65 | DIP / SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 0.50 | 0.039 | CF27 | 04-20 | Download | |||
| 0.50 | 0.039 | CF29 | 04-40 | SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 0.50 | 0.020 | CF31 | 04-61 | SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 0.50 | 0.020 | CF34 | 04-61 | SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 0.50 | 0.020 | CF35 | 04-40 | with | SMT | Download | |
| 0.50 | 0.020 | CF41 | Download | ||||
| 0.50 | 0.020 | CF42 | 02-50 | with | SMT | ZIF Side Entry FFC/FPC Connectors | Download |
| 0.50 | 0.020 | CF50 | 04-61 | SMT | ZIF One-Touch FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF55 | 6, 8, 11, 12, 13, 14, 36, 40 | SMT | ZIF FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF56 | 56, 60, 80 | SMT | ZIF One-Touch FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF61 | 04-60 | SMT | ZIF One-Touch FFC/FPC Connector | Download | |
| 0.50 | 0.020 | CF69 | 40 | Download | |||
| 0.50 | 0.020 | CF71 | Download | ||||
| 0.80 | 0.032 | CF32 | 04-40 | Download | |||
| 0.80 | 0.032 | CF37 | 04-40 | Download | |||
| 1.00 | 0.039 | CF06 | 4-15 | Download | |||
| 1.00 | 0.039 | CF07 | 04-32 | Download | |||
| 1.00 | 0.039 | CF08 | 04-32 | Download | |||
| 1.00 | 0.039 | CF09 | 04-32 | Download | |||
| 1.00 | 0.039 | CF10 | 04-32 | Download | |||
| 1.00 | 0.039 | CF11 | 04-30 | SMT | Download | ||
| 1.00 | 0.039 | CF16 | 03-32 | Download | |||
| 1.00 | 0.039 | CF20 | 04-27 | SMT | ZIF FFC/FPC Connector | Download | |
| 1.00 | 0.039 | CF23 | 03-19 | SMT | ZIF FFC/FPC Connector | Download | |
| 1.00 | 0.039 | CF25 | 04-32 | DIP / SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 1.00 | 0.039 | CF31 | 04-30 | SMT | ZIF One-Touch FFC/FPC Connectors | Download | |
| 1.00 | 0.039 | CF50 | 04-30 | SMT | ZIF One-Touch FFC/FPC Connector | Download | |
| 1.00 | 0.039 | CF65 | 04-35 | Download | |||
| 1.25 | 0.049 | CF01 | Download | ||||
| 1.25 | 0.049 | CF12 | 03-36 | Download | |||
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Remark | |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | |
|---|---|---|---|---|---|---|---|---|
| 0.80 | 0.032 | CHC3 | 06-36 | SMT | 2 | Download | ||
| 1.00 | 0.039 | CH07 | 02-40 | DIP / SMT | Male | 1 | Download | |
| 1.00 | 0.039 | CH16 | 6-100 | SMT | Male | 2 | Download | |
| 1.27 | 0.050 | CH01 | 04-50 | DIP / SMT | Male | 1 | Download | |
| 1.27 | 0.050 | CH02 | 04-50 | DIP / SMT | Male | 1 | Download | |
| 1.27 | 0.050 | CH03 | 04-50 | DIP / SMT | Male | 1 | Download | |
| 1.27 | 0.049 | CH06 | 6, 14, 26 | with | SMT | Male | 2 | Download |
| 1.27 | 0.050 | CH51 | 06-100 | DIP / SMT | Male | 2 | Download | |
| 1.27 | 0.050 | CH52 | 06-100 | DIP / SMT | Male | 2 | Download | |
| 1.27 | 0.050 | CH57 | 06-100 | DIP / SMT | Male | 2 | Download | |
| 1.27 | 0.050 | CHC2 | 06-100 | DIP / SMT | Male | 2 | Download | |
| 2.00 | 0.079 | CH11 | 02-40 | DIP / SMT | Male | 1 | Download | |
| 2.00 | 0.079 | CH21 | 02-40 | DIP / SMT | Male | 1 | Download | |
| 2.00 | 0.079 | CH70 | 04-80 | SMT | Male | 2 | Download | |
| 2.00 | 0.079 | CH71 | 04-80 | DIP / SMT | Male | 2 | Download | |
| 2.00 | 0.079 | CH72 | 08-50 | DIP | Male | 2 | Download | |
| 2.00 | 0.079 | CH74 | 06-68 | DIP / SMT | Male | 2 | Download | |
| 2.00 | 0.079 | CH75 | 04-80 | DIP / SMT | Male | 2 | Download | |
| 2.54 | 0.100 | CH31 | 01-40 | DIP / SMT | Male | 1 | Download | |
| 2.54 | 0.100 | CH34 | 02-40 | DIP / SMT | Male | 1 | Download | |
| 2.54 | 0.100 | CH81 | 04-80 | DIP / SMT | Male | 2 | Download | |
| 2.54 | 0.100 | CH85 | 04-80 | DIP / SMT | Male | 2 | Download | |
| 2.54 | 0.100 | CH87 | 06-64 | DIP / SMT | Male | 2 | Download | |
| 2.54 | 0.100 | CH88 | 10-64 | with | DIP | Male | 2 | Download |
| CHPT | Download | |||||||
| CHWG | Download | |||||||
| Pitch (m m) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | |
|---|---|---|---|---|---|---|---|---|
| 1.50 | 0.059 | CP14 | 2-10 | without | SMT | 1 | Download | |
| 1.50 | 0.059 | CP15 | 2-10 | without | SMT | Male/Female | 1 | Download |
| 2.00 | 0.079 | CP27 | 2.4 | without | SMT | Female | Download | |
| 2.50 | 0.098 | CP06 | 2-12 | without | Male/Female | Download | ||
| 2.50 | 0.098 | CP25 | 3 | without | SMT | Female | 1 | Download |
| 3.00 | 0.118 | CP35 | 2-12 | with | DIP / SMT | Male/Female | 1 | Download |
| 3.00 | 0.118 | CP35 | 2-24 | with | DIP / SMT | Male/Female | 2 | Download |
| 3.50 | 0.138 | CP05 | 2 | with | DIP / SMT | Male/Female | Download | |
| 3.68 | 0.145 | CP02 | 01-15 | with | Male/Female | Download | ||
| 4.00 | 0.157 | CP04 | 02, 03, 04, 05 | with | DIP / SMT | Male/Female | Download | |
| 4.20 | 0.165 | CP-011 | 3-5 | with | Female | 1 | Download | |
| 4.20 | 0.165 | CP-012 | 2-24 | with | Female | 2 | Download | |
| 4.20 | 0.165 | CP-012 | 3-5 | with | Male | 1 | Download | |
| 4.20 | 0.165 | CP-012 | 2-24 | with | Male | 2 | Download | |
| 4.20 | 0.165 | CP-013 | 2-24 | DIP | Male | 1 | Download | |
| 4.20 | 0.165 | CP-013 | 2-24 | DIP | Male | 2 | Download | |
| 4.20 | 0.165 | CP-014 | 2-24 | DIP | Male | 1 | Download | |
| 4.20 | 0.165 | CP-014 | 2-24 | DIP | Male | 2 | Download | |
| 5.00 | 0.197 | CP50 | 2-12 | with | DIP | Male/Female | Download | |
| 5.08 | 0.200 | CP32 | 4 | without | Male/Female | 1 | Download | |
| 5.08 | 0.200 | CP33 | DIP | Male/Female | 1 | Download | ||
| 6.30 | 0.248 | CP31 | Male/Female | Download | ||||
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | Rows | |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | |
|---|---|---|---|---|---|---|---|
| 1.27 | 0.050 | CA01 | 10-100 | IDC | Female | Download | |
| 1.27 | 0.050 | CA05 | 10-100 | IDC / DIP | Male | Download | |
| 1.27 | 0.050 | CA26 | 10-64 | IDC | Male | Download | |
| 1.27 | 0.050 | CA27 | 10-64 | IDC | Male | Download | |
| 1.27 | 0.050 | CA30 | 4-26 | IDC / DIP | Male | Download | |
| 1.27 | 0.050 | CA31 | 4-26 | IDC / DIP | Male | Download | |
| 1.27 | 0.050 | CA32 | 4-26 | with | DIP / SMT | Female | Download |
| 1.27 | 0.050 | CA33 | 4-26 | IDC | Female | Download | |
| 1.27 | 0.050 | CA34 | 4-26 | IDC / DIP | Male | Download | |
| 1.27 | 0.050 | CA35 | 4-26 | DIP / SMT | Male | Download | |
| 2.00 | 0.079 | CA11 | 6-64 | IDC | Female | Download | |
| 2.54 | 0.100 | CA21 | 6-64 | IDC | Female | Download | |
| 2.54 | 0.100 | CA23 | 6-64 | IDC / DIP | Male | Download | |
| Pitch (mm) | Pitch (inch) | Series | Pins | Latch | SMD / THT | Male / Female | |
| Pitch (mm) | Pitch (inch) | Series | Pins | SMD / THT | |
|---|---|---|---|---|---|
| 0.80 | 0.031 | CS60 | Download | ||
| 1.27 | 0.050 | CS21 | Download | ||
| 1.27 | 0.050 | CS22 | Download | ||
| 1.27 | 0.050 | CS61 | Download | ||
| 1.27 | 0.050 | CS62 | Download | ||
| 2.00 | 0.079 | CS01 | Download | ||
| 2.54 | 0.100 | CS02 | Download | ||
| 2.54 | 0.100 | CS05 | Download | ||
| 2.54 | 0.100 | CS07 | 6-48 | DIP | Download |
| 2.54 | 0.100 | CS08 | Download | ||
| 2.54 | 0.100 | CS09 | Download | ||
| 2.54 | 0.100 | CS10 | Download | ||
| 2.60 | 0.102 | CS30 | Download | ||
| CS59 | Download | ||||
| CS68 | Download | ||||
| CS69 | Download | ||||
| CS70 | Download | ||||
| CS76 | Download | ||||
| Pitch (mm) | Pitch (inch) | Series | Pins | SMD / THT | |
| Series | Pins | SMD / THT | Male / Female | |
|---|---|---|---|---|
| CD01 | 15, 26, 44, 62 | Solder Cup | Male / Female | Download |
| CD02 | Crimp | Male / Female | Download | |
| CD03 | 15, 26, 44, 62 | DIP | Male / Female | Download |
| CD04 | DIP | Male / Female | Download | |
| CD05 | 15, 26, 44 | DIP | Male / Female | Download |
| CD42 | Plastic Hood | Download | ||
| CD43 | Plastic Hood | Download | ||
| CD44 | Plastic Hood | Download | ||
| CD46 | Plastic Hood | Download | ||
| CD51 | 09, 15, 25, 37 | Solder Cup | Male / Female | Download |
| CD52 | 09, 15, 25, 37 | Crimp | Male / Female | Download |
| CD53 | 09, 15, 25, 37 | DIP | Male / Female | Download |
| CD54 | DIP | Male / Female | Download | |
| CD61 | 09, 15, 25, 37 | DIP | Male / Female | Download |
| CD62 | 09, 15, 25, 37 | DIP | Male / Female | Download |
| CD67 | DIP | Male / Female | Download | |
| CD71 | 09, 15, 25, 37, 50 | Solder Cup | Male / Female | Download |
| CD72 | 09, 15, 25, 37, 50 | DIP | Male / Female | Download |
| CD73 | 09, 15, 25, 37 | DIP | Male / Female | Download |
| CD76 | DIP | Male / Female | Download | |
| CD81 | Stacked | Male / Female | Download | |
| CD91 | 09, 15, 25, 37 | IDC HOUSING | Male / Female | Download |
| Series | Pins | SMD / THT | Male / Female | |
| Series | SMD / THT | Male / Female | Rows | Remark | |
|---|---|---|---|---|---|
| CU01 | SMT | Male / Female | Standard / Dual Type | USB 2.0 Type-A | Download |
| CU02 | SMT / DIP | Female | USB 2.0 Type-B | Download | |
| CU04 | SMT / DIP | Female | Mini USB 2.0 | Download | |
| CU05 | Download | ||||
| CU07 | Download | ||||
| CU09 | SMT | Female | Micro USB 2.0 | Download | |
| Series | SMD / THT | Male / Female | Rows | Remark | |
| Type | |
Contact Side | Shell Side | Mounting | CviLux Article Number |
|---|---|---|---|---|---|
| USB-C 24 Pin, DIP | Download | — |
DIP |
middle mount right angle |
CU1824PAM1N12-LF-HC |
| USB-C 24 Pin, SMT | Download | — |
SMT |
middle mount right angle |
CU1824PAM1N13-LF-HC |
| USB-C 24 Pin, PCB Clip Type | Download | PCB Clip Type |
— |
— |
CU1824PAC1N10-LF-HC |
| Typ | |
Contact Side | Shell Side | Mounting | CviLux Article Number |
|---|---|---|---|---|---|
| USB-C 24 Pin, DIP+SMT (double Shell) | Download | SMT | DIP + SMT (double Shell) |
middle mount right angle |
CU1824SAM1MP2RO-LF-HC |
| USB-C 24 Pin. DIP (single Shell) | Download | SMT | DIP (single Shell) |
middle mount right angle |
CU1824SAM1MD2R1-LF-HC |
| USB-C 24 Pin, DIP (double Shell) | Download | SMT | DIP (double Shell) |
middle mount right angle |
CU1824SAM1MD2RO-LF-HC |
| USB-C 24 Pin, DIP (single Shell) | Download | SMT + DIP | DIP (single Shell) |
top mount right angle |
CU1824SAH1PD2R1-LF-HC |
| USB-C 24 Pin, DIP | Download | SMT | DIP |
top mount right angle |
CU1824SAV1MD2RO-LF |
| USB-C 24 Pin, SMT (single Shell) | Download | SMT | SMT (single Shell) |
P.C.B. Clip Type |
CU1824SAC1MM2RO-LF-HC |
| USB-C 24 Pin, DIP (single Shell) | Download | SMT | DIP (single Shell) |
top mount right angle |
CU1824SAH1MD2RO-LF-HC |
| USB-C 24 Pin, DIP (double Shell) | Download | SMT + DIP | DIP (double Shell) |
top mount right angle |
CU1824SAH1PD2R0-LF-HC |
| USB-C 16 Pin, DIP (single Shell) | Download | SMT | DIP (single Shell) |
top mount right angle |
CU1816SAH1MD2RO-LF-HC |
| Type | Speed | Current | UL Cable | Lenght |
|---|---|---|---|---|
| USB 2.0 C to Micro B | 480 Mbps |
3 A |
80°C, 30 V |
< 2 Meter |
| USB 2.0 C to BM | 480 Mbps |
3 A |
80°C, 30 V |
< 4 Meter |
| USB 2.0 AM to C | 480 Mbps |
3 A |
80°C, 30 V |
< 4 Meter |
| USB 3.1 C to 3.0 Micro B | 10 Gbps |
3 A |
80°C, 30 V |
< 1 Meter |
| USB 3.1 C to 3.0 B | 10 Gbps |
3 A |
80°C, 30 V |
< 1 Meter |
| USB 2.0 C to Mini B | 480 Mbps |
3 A |
80°C, 30 V |
< 4 Meter |
| USB 3.1 C to A/F | 5 Gbps |
3 A |
80°C, 30 V |
< 0,15 Meter |
| USB 3.1 C to C | 10 Gbps |
3 A und 5 A |
80°C, 30 V |
< 2 Meter |
